90° Adjustable Swivel Mount for Ring Battery Doorbell (Formerly known as Generation 2 Doorbell 2020-2025)
Compatibility Check: Is This Your Doorbell?
This mount is designed for Ring Battery Doorbell (generation 2) ONLY NOT THE NEW 2026 GENERATION 2. The gen2 has a unique shape that's distinctly different from gen1 or the newer Pro versions.
(As an Amazon Associate, I earn from qualifying purchases.)
This mount DOES NOT fit Ring Battery Doorbell gen1 (the earlier, more square model). It also won't fit the Ring Battery Doorbell Pro.
Unsure? Send us a picture! Email shop@doorbellmount.com or text 1-833-326-6868. Check our Ring Model Guide.
Expand Your Ring Battery Doorbell gen2 View with 90° Adjustment
The Ring Battery Doorbell gen2 is sleek and compact, but sometimes you need to angle it more dramatically to capture what matters most. This 90° swivel mount offers full dual-axis control from 0° all the way to 90°, giving you the ultimate flexibility.
Whether your doorbell is mounted on a corner, angled wall, or needs to look down a porch, this mount delivers the range you need. Perfect for maximizing your view while keeping your setup clean and professional-looking.
Complete Dual-Axis Control (0-90°)
From flat to fully perpendicular, you have total control. Adjust both left/right and up/down within the full 90° range. No blind spots, no compromise—just precise aiming.
Smart Base Design: Mount vertically or horizontally depending on your trim or siding. The doorbell stays upright in either configuration.
Mount Dimensions
- Base Width: 1.8 inches
- Base Height: 3.1 inches
- Base Hole Spacing: 2-5/8 inches (center-to-center)
- Total Extension (@ 0° Angle): Approx. 1.5 inches from wall
- Total Extension (@ 90° Angle): Approx. 3.0-3.5 inches from wall (depends on exact angle)
Key Features & Benefits:
- Perfect Fit: Exclusively designed for Ring Battery Doorbell (gen2) - Verify Your Model!
- Full Range (0-90°): Dual-axis swivel for maximum viewing angles.
- Robust Extension: Extends further from wall than 35° mounts for dramatic angles.
- Secure Angle Lock: Set screws included (likely #4 / PH1) to hold your chosen angle firmly.
- Flexible Installation: Base mounts vertically or horizontally. Fits surfaces up to 1.8" wide. Adapters for narrower spots available (down to 1/2").
- Wire Management: Convenient central hole for doorbell wiring.
- Weather Resilient: Made from durable PETG plastic rated for outdoor use.
- Complete Hardware Set: All screws and fasteners for base, bracket, doorbell, and angle locking included.
How to Install Your 90° Swivel Mount
-
Prepare Tools & Area: Gather necessary tools:
- Drill (with appropriate bits).
- Screwdrivers/Bits: PH2 Philips (#6 base screws) AND PH1 Philips (#4 bracket/set/doorbell body screws provided by us). Use correct size!
- Wall anchors (if needed). Level (optional).
Turn OFF power to doorbell wiring at the breaker before starting!
-
Mount the Base: Route wires through the base piece. Position base (screws vertical or horizontal) and attach securely using provided #6 screws (PH2 driver) or suitable anchors.
Drill Warning: Use low speed/clutch. Do not overtighten (risk of stripping screws or cracking plastic).
-
Attach Swivel Bracket: Route wires through the swivel bracket. Align onto base and attach using the four center screws provided (likely #4 screws / PH1 driver).
Stripping Warning: Use correct PH1 driver. Tighten snugly by hand first, avoid overtightening with drill.
- Set Initial Angle: Adjust swivel bracket (up/down & left/right) within the 0-90° range. Lightly tighten one/two set screws (likely underside, #4 / PH1 driver).
- Wire Your Doorbell: Connect wires following Ring's instructions. Tuck excess wire into the mount cavity.
-
Attach Doorbell to Mount Bracket:
- Align your Ring Battery Doorbell gen2 with the pre-drilled holes on the swivel mount bracket.
- Secure doorbell using the shorter screws PROVIDED WITH THIS MOUNT (likely #4 screws / PH1 driver).
- DO NOT USE screws that came with your doorbell (they may be too long).
- Replace cover if applicable.
Stripping Warning: Use correct PH1 driver for provided screws. Tighten snugly, do not overtighten with drill.
-
Finalize Angle & Secure: Make final angle adjustments. Fully tighten all set screws using the correct driver (likely PH1) and gentle pressure.
Do not overtighten set screws with a drill!
Turn power back on and test.
Always follow safety precautions & Ring's wiring instructions. Use appropriate anchors. Use the correct size Philips driver (PH1 for #4, PH2 for #6) to avoid stripping.
Why Choose the 90° Swivel Mount?
Capture the Complete Picture
With a full 90° range, you can position your Ring Battery Doorbell gen2 to capture wide areas, angled approaches, or even straight down if needed. This mount eliminates blind spots that smaller-angle mounts can't reach.
Durable, Professional Look
The robust PETG construction ensures years of reliable performance in all weather. Plus, the clean design keeps your installation looking professional while providing maximum functionality.
Installation Concept Videos
General installation concept shown below:
Verify Compatibility or Ask Questions!
Double-check your model! If you're not 100% certain you have the Ring Battery Doorbell gen2, please send us a picture before ordering!
- Email: shop@doorbellmount.com
- Text/Call: 1-833-326-6868
Need adapters for narrow trim? Contact us!
Standard Color: Black. Need a different color? Please purchase the separate Color Change Request listing along with this mount.
Angle Range Note: This mount provides an adjustable range from approximately 0° (flat) to 90° relative to the mounting surface. The exact angle achieved depends on installation specifics.
3D Printed Quality: While 3D printing provides really good production quality parts, there are often minor imperfections that may be found on the prints. These do not impair the function and rarely affect the aesthetics. But if you're not happy with the quality, please text, email, or message me before leaving a review.
Order your 90° Adjustable Swivel Mount today and maximize your Ring Battery Doorbell gen2 coverage!
