Ring Wired Doorbell Pro (Pro 2) Standard Offset Brick Extension Mount (5/8")
Compatibility: Ring Wired Doorbell Pro (Pro 2) ONLY!
- Fits ONLY: The model currently called Ring Wired Doorbell Pro (also widely known as the Pro 2). This model has a slightly curved back and uses 2 mounting screw holes.
- Confirm your model matches the images below:
-
(Example Images - Click first two for Amazon Link. As an Amazon Associate, I earn from qualifying purchases.) - WILL NOT FIT: The Ring Wired Doorbell Plus (formerly called Ring Pro / Pro 1 - has flat back w/ ridges) or ANY other Ring model (Battery versions, Wired 2021, etc.).
- Surface Width: Requires mounting surface (trim/molding) to be AT LEAST 9/16 inches wide for the base.
Ring's naming causes confusion! Please double-check or send us a photo. Check our Ring Model Guide or contact us!
Extend Your Ring Pro 2 Past Brick with Standard Offset!
Is your Ring Wired Doorbell Pro (Pro 2) mounted on trim that's set back from your brick or stone siding? This **Standard Offset Brick Extension Mount** brings your doorbell forward for improved visibility and access, while providing our popular standard sideways offset.
It mounts easily to your existing trim (minimum 9/16" wide) without drilling into masonry, positioning your Pro 2 correctly relative to the brick face.
How it Works: Standard Offset (5/8")
This mount features our widely compatible STANDARD OFFSET, which shifts the center of your Ring Pro 2 approximately 5/8 inches horizontally towards the brick side relative to the center of the narrow 9/16" mount base. This typically leaves about 3/8 inch of the base visible near the door frame.
This configuration works well for most installations, partially positioning the doorbell over the adjacent brick and providing good door clearance.
This mount positions the doorbell over or in front of the brick face, not flush with it.
Standard Offset (This Product) vs Full Offset:
Need Maximum Sideways Clearance? Click here for the Full Offset version.
Base Dimensions & Mounting: The extension base is 9/16 inches wide (requires >= 9/16" surface). Standard mounting hole spacing is 2.5 inches (center-to-center). Ensure solid mounting on trim. Wall-mounting screws not included.
Angled Trim? If your trim is angled, add our Angle Shims (sold separately) to ensure a perpendicular mount.
CRITICAL: Measure & Select Your Extension Length!
Choose the correct length to clear your brickwork. Measure carefully:
- Measure the exact distance straight out from the surface where the mount base will attach (your trim) to the outermost face of your brick.
- Order THIS measurement as your required Extension Length. (Do NOT subtract doorbell thickness for offset mounts).
Select the required extension length from the dropdown menu when ordering. (Starts at 1/4 inch).
Need help measuring? Text/email a picture! (Contact info below)
Key Features & Benefits:
- Tailored Fit: Specifically for Ring Wired Doorbell Pro (Pro 2) with curved back.
- Standard 5/8" Offset: Provides good sideways positioning for many situations.
- "Over Brick" Placement: Extends doorbell forward past brick, positioning it partially over the brick face.
- Avoid Drilling Brick: Mounts to existing trim (>=9/16" wide, Std. 2.5" hole spacing).
- Selectable Extension Length: Order the precise depth needed (Trim-to-Brick measurement).
- Narrow Base (9/16" Std): Designed for standard trim widths.
- Wire Passthrough: Internal channel accommodates wiring.
- Durable PETG Construction: Strong, weather-resistant plastic.
- Add-on Compatible: Works with angle shims, fillers etc. (see below).
- Future-Proof Bracket: Top adapter bracket potentially replaceable for future upgrades (check compatibility).
How to Install Your Standard Offset Extension
This mount uses two main printed pieces: the Extension Base and the Doorbell Adapter Bracket.
-
Tools & Prep: Gather: Drill, PH1 & PH2 Philips Screwdrivers/Bits, Level, Anchors (if needed), Ring security screwdriver/bit (from doorbell box).
Turn OFF power at the breaker!
-
Mount Extension Base: Position the Extension Base (correct length/offset) on trim over wires (ensure offset provides desired clearance). Attach securely using appropriate screws (#6 size likely, use PH2) and anchors if needed into the 2.5" spaced holes.
Ensure base is level. Drill pilot holes. Don't overtighten.
-
Attach Doorbell Adapter Bracket: Route wires through the Doorbell Adapter Bracket (top piece for Pro 2). Align onto Extension Base. Attach using the four small center screws provided (likely #4 screws / PH1 driver).
Use correct PH1 bit. Tighten until flush. Check for/clear debris if needed. Do NOT over-torque.
- Wire Doorbell: Connect wires to your Ring Wired Doorbell Pro following Ring's instructions. Tuck excess wire into base cavity.
-
Attach Ring Doorbell Pro (Pro 2):
- Align the main **BODY** of your Ring Wired Doorbell Pro onto the Doorbell Adapter Bracket.
- Secure the **doorbell body** to the Adapter Bracket using the small screws PROVIDED WITH THIS MOUNT (typically #4 / PH1 driver). Do NOT use Ring's wall screws here.
- Once the body is secure, attach the Ring Wired Doorbell Pro **FACEPLATE** using the security screw(s) and tool PROVIDED BY RING.
Use correct drivers/tools for each screw type. Tighten gently. - Final Check & Power On: Ensure doorbell is secure. Turn power back on and test.
Follow safety rules & Ring's guidelines. Use correct anchors/screws for wall type. Correct screwdriver size prevents stripping.
How the Wired Doorbell Pro Brick Extension Enhances Your Doorbell
Improved Placement Flexibility
The Standard Offset Brick Extension ensures your Ring Wired Doorbell Pro (Pro 2) camera has an optimal view when mounted on recessed trim, helping capture important details. This standard offset provides good visibility and accessibility for many installations.
Simple Installation Process
Installing this extension is straightforward. Mount the base to your existing trim (avoiding brick drilling!), attach the adapter bracket, select your extension length, and mount your doorbell. Designed for easy homeowner installation.
Durable and Weather-Resistant
Crafted from durable PETG plastic, this brick extension withstands outdoor conditions, ensuring your Wired Doorbell Pro remains securely mounted and operational year-round.
Optional Add-ons & Accessories:
Further customize your installation:
-
Angle Shims (5°, 10°, 15°)Corrects for angled trim *under the Extension Base*.
-
Horizontal Angle Adapter or Swivel Add-onAdd horizontal angle adjustment to the end of the extension.
-
Bottom Filler Spacer PlateFills the gap below the extension base on angled/uneven trim.
-
Body Shim Filler PlateFills gaps between the extension body and uneven brick.
-
Add Side Wire EntryAdds side entry holes ("mouse holes") to the *Extension Base* (add service to cart).
Product Examples
(See listing photos for details or contact us for more examples!)
Need Help? Confirm Compatibility & Measurements!
Ring model names are challenging! Ensure you have the Wired Doorbell Pro (Pro 2). Need help measuring extension length?
- Email: shop@doorbellmount.com (Send Pictures!)
- Text/Call: 1-833-326-6868 (Text Pictures!)
Standard Color: Black. For other colors, add the Color Change Request item.
Doorbell Not Included. Includes the 2-piece extension mount (Extension Base + Doorbell Adapter Bracket) and necessary assembly screws.
PETG Material: Printed in durable, outdoor-rated PETG.
3D Printed Quality: Minor cosmetic variations inherent to 3D printing may exist but do not affect function. Contact us with quality concerns before reviewing.
Order the Standard Offset Brick Extension for your Ring Wired Doorbell Pro (Pro 2) today! Remember to measure carefully (Trim to Brick Face!) and select your required extension length.
