15-90° Adjustable Swivel Mount for Wyze Wireless Duo Cam Doorbell (2024) | 2K Dual Cam | Adjustable Wide-Arc Bracket

$50.00
$40.00
Custom 15-90° Pivot Mount for the Wyze Wireless Duo Cam Doorbell — Aim BOTH Lenses Off the Side Wall Built for the Wyze Wireless Duo Cam Doorbell (released October 2024) — the only Wyze doorbell with two cameras: a 2K...
Availability: Many In Stock
Product Type: Adjustable Mount 15-90°

Custom 15-90° Pivot Mount for the Wyze Wireless Duo Cam Doorbell — Aim BOTH Lenses Off the Side Wall

Built for the Wyze Wireless Duo Cam Doorbell (released October 2024) — the only Wyze doorbell with two cameras: a 2K head-on lens for visitors and a downward-angled 1080p package lens. The bent-neck 15-90° pivot tilts the entire dual-camera assembly perpendicular to the wall, so BOTH lenses end up where they should: top lens at faces, bottom lens at the package zone. Set-screw locked, made-to-order in the USA, ships matte black in UV-stable PETG.

Side-wall installs are especially punishing for two-camera doorbells — the offset angle multiplies. A small mis-aim that's just "OK" for a single-camera doorbell becomes a pair of misaligned framings on the Duo Cam. The wide-arc 15-90° pivot fixes both at once.

Custom-Fit for the Wyze Wireless Duo Cam Doorbell

  • This bracket is shaped specifically for the Wyze Wireless Duo Cam Doorbell — Amazon ASIN B0DCJB43TH (with chime included). Wyze's flagship battery doorbell with TWO cameras: a 2K head-on lens and a downward-facing 1080p package lens. Built-in non-removable lithium battery (3-6 months), color night vision on both lenses, AI human/package detection, no monthly fee, IP65 weather rating.
  • Does NOT fit: the Wyze Video Doorbell v1, v2, single-cam Pro, or new 2025 Battery Video Doorbell — each has only ONE camera and a totally different body shape. The Duo Cam has a tall vertical body with TWO visible lenses stacked. Other Wyze models have their own listings. Also does not fit Ring, Nest, Eufy, or any non-Wyze brand.
  • Quick Wyze identification: If your doorbell has TWO visible camera lenses (top + bottom), it's the Duo Cam — this listing. If it has only one lens, it's a different Wyze model.
Don't have the doorbell yet? Get the Wyze Wireless Duo Cam Doorbell on Amazon →

Side-Wall Aim, Both Cameras On Target

The Duo Cam's whole pitch is the second camera: a downward lens that watches the doormat and packages while the top camera handles visitor faces. Wyze pre-angles the bottom lens roughly 30° downward by design so it points at the porch floor when the doorbell is mounted square to the wall. That works perfectly... and falls apart on side-wall installs.

This 15-90° bent-neck pivot rotates the entire dual-camera assembly outward perpendicular to the wall, so BOTH lenses recover their intended framing: the 2K top lens captures visitor faces approaching the door, and the 1080p bottom lens watches the package zone. Set the angle once with the set screws and walk away — the Duo Cam runs 3-6 months between charges, and the lock is rated for years.

Wide Dual-Axis Control (15-90°) — Tuned for the Wyze Duo Cam Doorbell

Bent-neck swivel joint — precise aiming control across a 15° to 90° arc relative to the wall. Excels at angles greater than 45°. Fine-tuning works horizontally and vertically. Locking set screws hold position permanently.

15-90 degree side-wall swivel mount adjustability diagram for Wyze Wireless Duo Cam Doorbell
15° to 90° pivot — dual-axis swivel for perpendicular-wall installs.

Need a smaller adjustment? See our 0-35° Swivel Mount for the Wyze Duo Cam Doorbell for fine-tuning on flat-wall installs.

Mount Dimensions & Weight

  • Base Width: 1.8 inches
  • Base Height: 3.1 inches
  • Base Hole Spacing: 2-5/8 inches (center-to-center)
  • Wall Extension at 15°: ~2.0 inches
  • Wall Extension at 90°: ~3.5 inches (extends doorbell perpendicular to wall)
  • Weight: ~2 oz (PETG mount only)
  • (Note: This is the standard 1.8" base; narrow 3/4" baseplate option available — see Customization section.)

Key Features & Benefits

  • Custom-Fit for Duo Cam Body: Tall pocket cradles the dual-camera body without blocking either lens.
  • Both Lenses Stay Free: Mount geometry avoids both the 2K top lens and the 1080p bottom package lens — no edge crop, no shadow.
  • Wide 15-90° Pivot Range: Tilts the whole assembly perpendicular to the wall — both cameras recover their intended framing.
  • Two-Axis Aim: Vertical tilt + horizontal pan; both axes lock independently with set screws.
  • USB-C Port Reachable: Designed so the charging port stays accessible for in-place top-up every 3-6 months.
  • Battery-First Friendly: No wiring required — install in 15-20 minutes.
  • Outdoor PETG: Matches the Duo Cam's IP65 rating — UV-stable, freeze-tolerant.
  • Siding Compatible: Flat surfaces or lapped siding up to 1.8" wide.
  • Universal Base: Switch doorbells later by swapping the ~$10 adapter; the swivel base stays on the wall.
  • Complete Kit: Bent-neck pivot base, custom Duo Cam adapter, set screws, mounting screws + anchors.

Customization & Add-On Options

Installing Your 15-90° Side-Wall Mount on the Wyze Duo Cam Doorbell

  1. Tools & Prep: Drill, PH2 Philips (#6 base screws), PH1 Philips (#4 bracket / set screws / doorbell screws — provided preinstalled to the bracket), wall anchors if needed, level.
    Battery-only doorbell — no transformer required. Charge the Duo Cam fully via USB-C (~5 hours) BEFORE mounting so you can verify Live View aim at install time.
  2. Pair the Chime First: Plug the included Wyze Chime into a power outlet inside the house and pair to the Duo Cam through the Wyze app. Easier indoors before the doorbell goes up the wall.
  3. Plan the Aim Angle: Stand where visitors approach. The Duo Cam needs the TOP lens at face height for the visitor and the BOTTOM lens covering the doormat. On a side-wall install you'll need a 60-90° pivot — pre-visualize it before drilling.
  4. Mount the Base: Position the bent-neck base vertically on your siding/trim. Screw in with #6 screws (PH2 driver), anchors as needed.
    Drill pilot holes if mounting into hard trim wood.
  5. Attach the Bent-Neck Swivel Bracket: Align the swivel onto the base and attach using four center #4 / PH1 screws.
  6. Set Initial Angle: Adjust the bent-neck through the 15-90° range so the doorbell's TOP lens points at visitor face height. Lightly tighten one or two set screws for now — final tightening comes after Live View.
  7. Snap the Duo Cam Into the Bracket: Use the screws PROVIDED WITH THIS MOUNT (these come preinstalled in the bracket so you can see exactly where each screw goes). Do NOT use Wyze's wedge plate or 3M adhesive method.
    Use the correct PH1 driver for provided screws. Do not overtighten.
  8. Aim Both Cameras Using Live View: Open the Wyze app → Live View → tilt and pan the swivel until BOTH cameras frame correctly: top lens covers visitor face zone, bottom lens watches doormat / package area. Tighten all set screws.
    Hand-tight on set screws. Over-tightening cracks the joint.
  9. Test Package Detection: In the Wyze app, configure Person and Package detection zones for the new angle. Drop a test package on the porch and confirm the bottom camera catches it. Check that the top camera still gets a clean visitor face when someone walks up.

Tip: the bottom lens has roughly 30° of built-in downward bias by design. On a 90° side-wall pivot, that downward bias starts pointing AT the porch instead of straight down at the doormat — usually a good thing. Verify both views in Live View before walking away.

FAQ — Wyze Duo Cam Doorbell 15-90° Mount

Is this mount compatible with the Wyze Duo Cam Doorbell?
Yes — custom-shaped for the Wyze Wireless Duo Cam Doorbell (B0DCJB43TH). Will not fit the v1, v2, single-cam Pro, or new 2025 Battery Video Doorbell.
How is this 15-90° mount different from the 0-35° version?
The 15-90° mount is for side-wall installs where the doorbell sits perpendicular to the door (significant pivot). The 0-35° mount is for fine-tuning aim on a flat-wall install.
Will both lenses still work after mounting?
Yes — the bracket is designed to leave both the 2K top lens and the 1080p bottom package lens unobstructed. Live View will confirm both feeds at install time.
Can I install on vinyl siding without drilling?
Yes. Pair this with our Vinyl Siding Adapter for a no-drill install. For Hardie / fiber-cement, use the Hardie Siding Mount.
Does the mount support the Duo Cam's package detection zone?
Yes — that's the main reason side-wall Duo Cam installs need a real pivot mount. With the doorbell square to a side wall, the bottom lens stares into siding instead of the doormat. The 15-90° pivot reorients both cameras so package detection works as designed.
How accessible is the USB-C charging port?
Fully reachable from below without dismounting the doorbell — you can plug in a USB-C cable and recharge in place. Useful since the Duo Cam needs a charge every 3-6 months.
Is this mount weatherproof?
Yes. UV-stable PETG, freeze-tolerant, sealed against rain — matches the Duo Cam's IP65 rating.

✔ Replacement Guarantee — The Right Part, Guaranteed

Send a picture of your install area and your doorbell BEFORE you order. We'll send you the exact link to what you need. If you order and it doesn't fit, we'll send the correct part at NO ADDITIONAL COST.

  • Before you order: Text or email pictures of (1) your install location and (2) your doorbell. We'll confirm the exact product/variant that fits and send a direct link.
  • If the part doesn't fit: Send a picture of the doorbell and a picture of how the part doesn't fit. We'll ship the correct replacement at no extra cost.
  • How to send pictures: Upload them on this listing during checkout, OR text/email them to 833-326-6868 / shop@doorbellmount.com. Send before purchase or immediately after (must arrive before we ship).

This guarantee covers fitment issues only. We can't replace parts damaged during install or after install.

Need to Buy Your Wyze Doorbell?

Quick affiliate links to the full Wyze video doorbell lineup:

Affiliate Disclosure: As an Amazon Associate, DoorbellMount.com earns from qualifying purchases at no extra cost to you. Pricing is controlled by Amazon and may change.

Questions? Need Help?

Standard Color: Ships in Black. For other colors, use the Color Change Request.

Angle Note: The term “15-90°” represents the approximate adjustment range for perpendicular installations. Actual achievable angle depends on positioning.

3D-Printed Parts: Minor cosmetic variations or layer lines may be present and do not affect strength or weather resistance. Each mount is printed-to-order in our USA shop.

Pick up the right pivot mount for your Wyze Duo Cam — lock both 2K + package cameras on target on a side-wall install.
