SimpliSafe Doorbell Pro Full Offset Brick Extension Mount | Max Clearance
Compatibility: SimpliSafe Video Doorbell Pro ONLY!
- Fits ONLY: The **SimpliSafe Video Doorbell Pro**.
- Confirm your model matches the picture below:
-
(Example Images - Click first for Amazon Link. As an Amazon Associate, I earn from qualifying purchases.) - WILL NOT FIT: Any other SimpliSafe products or doorbells from other brands (Ring, Nest, Eufy, etc.).
- Surface Width: Requires mounting surface (trim/molding) to be AT LEAST 9/16 inches wide for the base.
Please double-check your SimpliSafe model before ordering!
Maximum Door Clearance for Your SimpliSafe Doorbell Pro!
Is your SimpliSafe Video Doorbell Pro mounted on trim recessed behind brick? Need maximum clearance from a tight door swing or storm door? This **Full Offset Brick Extension Mount** is the solution!
It extends your SimpliSafe Pro forward past the brick (select required length) and uses our **Full Offset** design to shift the doorbell entirely sideways over the brick face, maximizing space. Installs easily on narrow trim (>= 9/16" wide) without drilling into masonry.
How it Works: Full Offset (Maximum Sideways Shift)
This mount utilizes our unique FULL OFFSET geometry. Your SimpliSafe Doorbell Pro attaches so its door-facing edge aligns flush with the side edge of the narrow 9/16" mount base. This provides the maximum possible horizontal shift over adjacent brick compared to our Standard Offset mounts.
Ideal when maximum clearance from a door swing or storm door is critical. The offset is reversible for left or right installation.
This mount positions the doorbell over or in front of the brick face.
Full Offset (This Product) vs Standard Offset:
Need standard (less) offset? Click here for the Standard Offset version for the SimpliSafe Pro.Base Dimensions & Mounting: The extension base is 9/16 inches wide (requires >= 9/16" surface). Standard mounting hole spacing is 2.5 inches (center-to-center). Ensure solid mounting on trim. Wall-mounting screws not included.
Angled Trim? If your trim is angled, add our Angle Shims (sold separately) for a perpendicular installation.
CRITICAL: Measure & Select Your Extension Length!
Choose the correct length to clear your brickwork or storm door. Measure carefully:
- Measure the exact distance straight out from the surface where the mount base will attach (your trim) to the outermost face of your brick or obstacle.
- Order THIS measurement as your required Extension Length. (Do NOT subtract doorbell thickness for offset mounts).
Select the required extension length from the dropdown menu when ordering. (Starts at 1/4 inch).
Need help measuring? Text/email a picture! (Contact info below)
Measure like this from Trim to Brick Face for Extension Length.
Key Features & Benefits:
- Maximum Sideways Offset: Full Offset design provides ultimate door swing clearance.
- Tailored for SimpliSafe Pro: Ensures compatibility with the SimpliSafe Video Doorbell Pro.
- "Over Brick" Placement: Extends doorbell forward past brick and positions it fully over the brick face.
- Avoid Drilling Brick: Mounts to existing trim (>=9/16" wide, Std. 2.5" hole spacing).
- Selectable Extension Length: Order the precise depth needed (Trim-to-Brick/Obstacle measurement).
- Narrow Base (9/16" Std): Designed for tight trim installations.
- Wire Passthrough: Internal channel accommodates SimpliSafe wiring.
- Reversible Offset: Base can be flipped for left or right offset.
- Durable PETG Construction: Strong, weather-resistant plastic.
- Add-on Compatible: Works with angle shims, fillers etc. (see below).
- Future-Proof Bracket: Top adapter bracket potentially replaceable for future upgrades (check compatibility).
How to Install Your Full Offset Extension for SimpliSafe Pro
This mount uses two main printed pieces: the Extension Base and the Doorbell Adapter Bracket.
-
Tools & Prep: Gather: Drill, PH1 & PH2 Philips Bits, Level, Anchors (if needed), your SimpliSafe Doorbell Pro mounting bracket & hardware.
Turn OFF power at the breaker!
-
Mount Extension Base: Position the Extension Base (correct length/offset) on trim over wires (ensure Full Offset provides max clearance needed). Attach securely using appropriate screws (#6 size likely, use PH2) and anchors into the 2.5" spaced holes.
Ensure base is level. Don't overtighten.
-
Attach Doorbell Adapter Bracket: Route wires through the Doorbell Adapter Bracket (top piece for SimpliSafe). Align onto Extension Base. Attach using the four small center screws provided (likely #4 screws / PH1 driver).
Use correct PH1 bit. Tighten until flush. Check for/clear debris if needed. Do NOT over-torque.
-
Attach SimpliSafe Bracket: Secure the **metal mounting bracket that came WITH your SimpliSafe Doorbell Pro** onto the Doorbell Adapter Bracket using the small screws PROVIDED WITH THIS MOUNT (typically #4 / PH1). Ensure correct orientation.
Do NOT use SimpliSafe's long wall screws here. Use correct PH1 driver.
- Wire & Mount SimpliSafe Pro: Connect wires to the SimpliSafe bracket following SimpliSafe instructions. Slide the SimpliSafe Doorbell Pro unit onto its bracket until it clicks securely. Tighten security screw if applicable.
- Final Check & Power On: Ensure doorbell is secure. Turn power back on and test.
Follow safety rules & SimpliSafe guidelines. Use correct anchors/screws. Correct screwdriver size prevents stripping.
Enhance Your Security with the Simplisafe Doorbell Extension
Introduction to the Simplisafe Doorbell Brick Extension
This Full Offset Brick Extension is designed for homeowners needing to install their SimpliSafe Doorbell Pro securely near brick walls or with tight door clearances. This extension solves common installation challenges by providing flexibility and improved positioning.
Benefits of Using the Brick Extension
The durable PETG design withstands outdoor conditions, ensuring long-lasting performance. The full offset prevents the doorbell from being obstructed by brick or hit by a door, providing a clear view and enhanced security functionality.
Installation Made Simple
Installing the Brick Extension is straightforward onto existing trim. Mount the base, attach the adapter, select your length, and mount your SimpliSafe bracket using the included hardware and instructions for a hassle-free setup.
Optional Add-ons & Accessories:
Further customize your installation:
-
Angle Shims (5°, 10°, 15°)Corrects for angled trim *under the Extension Base*.
-
Horizontal Angle Adapter or Swivel Add-onAdd horizontal angle adjustment to the end of the extension.
-
Bottom Filler Spacer PlateFills the gap below the extension base on angled/uneven trim.
-
Body Shim Filler PlateFills gaps between the extension body and uneven brick.
-
Add Side Wire EntryAdds side entry holes ("mouse holes") to the *Extension Base* (add service to cart).
-
Wire Extension Kit
Need longer wires? Purchase our extension wire kit with your choice of connectors.
Standard color is White (Matches SimpliSafe). Add this service for Black or other colors.
Product Examples
(See listing photos for details or contact us for more examples!)
Need Help? Confirm Compatibility & Measurements!
Ensure you have the SimpliSafe Video Doorbell Pro. Need help measuring extension length or choosing Full vs Standard Offset?
- Email: shop@doorbellmount.com (Send Pictures!)
- Text/Call: 1-833-326-6868 (Text Pictures!)
Standard Color: White (to match SimpliSafe). For Black or other colors, add the Color Change Request item.
Doorbell Not Included. Includes the 2-piece extension mount (Extension Base + Doorbell Adapter Bracket) and necessary assembly screws.
PETG Material: Printed in durable, outdoor-rated PETG.
3D Printed Quality: Minor cosmetic variations inherent to 3D printing may exist but do not affect function. Contact us with quality concerns before reviewing.
Order the Full Offset Brick Extension for maximum clearance with your SimpliSafe Video Doorbell Pro! Remember to measure carefully (Trim to Brick Face!) and select your required extension length.
